This function compares future climate projections from multiple General Circulation Models (GCMs) based on their similarity in terms of variables. The function uses three clustering algorithms — k-means, hierarchical clustering, and closestdist — to group GCMs, and generates visualizations for the resulting clusters.
Usage
compare_gcms(
s,
var_names = c("bio_1", "bio_12"),
study_area = NULL,
scale = TRUE,
k = 3,
clustering_method = "closestdist"
)Arguments
- s
A list of stacks of General Circulation Models (GCMs).
- var_names
Character. A vector with the names of the variables to compare, or 'all' to include all available variables.
- study_area
An Extent object, or any object from which an Extent object can be extracted. Defines the study area for cropping and masking the rasters.
- scale
Logical. Whether to apply centering and scaling to the data. Default is
TRUE.- k
Numeric. The number of clusters to use for k-means clustering.
- clustering_method
Character. The clustering method to use. One of: "kmeans", "hclust", or "closestdist". Default is "closestdist".
Value
A list with two items: suggested_gcms (the names of the GCMs suggested for further analysis) and statistics_gcms (a grid of plots visualizing the clustering results).
Examples
var_names <- c("bio_1", "bio_12")
s <- import_gcms(system.file("extdata", package = "chooseGCM"), var_names = var_names)
study_area <- terra::ext(c(-80, -30, -50, 10)) |> terra::vect(crs="epsg:4326")
compare_gcms(s, var_names, study_area, k = 3, clustering_method = "closestdist")
#> Warning: The `<scale>` argument of `guides()` cannot be `FALSE`. Use "none" instead as
#> of ggplot2 3.3.4.
#> ℹ The deprecated feature was likely used in the factoextra package.
#> Please report the issue at <https://github.com/kassambara/factoextra/issues>.
#> $suggested_gcms
#> $suggested_gcms$k2
#> [1] "cr" "hg"
#>
#> $suggested_gcms$k3
#> [1] "ae" "ch" "cr"
#>
#> $suggested_gcms$k4
#> [1] "cc" "ev" "me" "ml"
#>
#> $suggested_gcms$k5
#> [1] "ae" "me" "mr" "cr" "in"
#>
#> $suggested_gcms$k6
#> [1] "ae" "ch" "cr" "ml" "ev" "in"
#>
#> $suggested_gcms$k7
#> [1] "ch" "mr" "ae" "hg" "ev" "gg" "in"
#>
#> $suggested_gcms$k8
#> [1] "cc" "ev" "me" "ml" "gg" "in" "hg" "mr"
#>
#> $suggested_gcms$k9
#> [1] "ae" "cc" "hg" "cr" "ch" "me" "mr" "gg" "ev"
#>
#> $suggested_gcms$k10
#> [1] "ae" "cc" "hg" "cr" "ch" "me" "mr" "gg" "ev" "ml"
#>
#>
#> $statistics_gcms
#>
